Mobile crusher are widely used in mines, quarries, construction waste treatment and engineering construction projects. Compared with fixed production lines, mobile crushers feature high integration, flexible relocation and rapid commissioning on-site. Correct startup operation is not only related to the service life of equipment, but also directly affects on-site personnel safety. This article systematically introduces the standard startup procedures and precautions for mobile crushers, applicable to crawler or wheeled mobile crushing stations.
I. Pre-start Inspection
Before pressing the start button, the following inspection items must be completed:
1. Overall Equipment Inspection
Check for personnel or obstacles around and inside the equipment.
Confirm all safety guards and railings are in place and firmly fixed.
Inspect key parts such as conveyor belts, vibrating screens and crushing chambers for stuck objects or residual materials.
Ensure hydraulic outriggers or supporting devices are properly retracted or supported in accordance with operating requirements.
2. Lubrication and Oil Level Check
Check the engine oil level of diesel-powered models or electric motor oil condition of electric-driven equipment.
Inspect the grease condition of the main crushing bearing and ensure sufficient grease in the lubrication system.
For hydraulic drive or auxiliary systems, check the hydraulic oil level and oil quality.
Verify the coolant liquid level for diesel engine models.
3. Electrical and Control System
Check if all indicator lights and instruments on the control panel work normally.
Confirm the emergency stop button has been reset.
Inspect cable connections for electric-driven equipment or battery power for diesel models.
Check signal connection between the remote control or control cabinet and the main unit.
4. Belt and Tensioning Device
Check the tension degree of engine or motor belts.
Inspect wear and tension conditions of crusher drive belts (if equipped).
Check conveyor belts for deviation tendency or damage.
II. Standard Startup Process
Mobile crushers generally adopt graded sequential startup, starting from downstream equipment to upstream units to prevent material blockage.
Typical startup steps (taking diesel-electric hybrid or full hydraulic driven crawler crushing station as an example):
Step 1: Start the engine or connect the main power supply
Diesel model: Turn the start key to "ON". After the preheating indicator goes out, turn to "START" to start the engine and keep idling for 3-5 minutes.
Electric model: Close the main circuit breaker and check if the voltage of the control cabinet is within the rated range.
Step 2: Start the hydraulic system (if applicable)
Some crawler mobile crushers need to start the hydraulic pump motor or hydraulic oil radiator first to support auxiliary operations such as crawler walking, hopper folding and discharge opening adjustment.
Step 3: Launch downstream conveying equipment
Start the main discharge conveyor belt first.
Then start the side discharge conveyor belt (if equipped).
Next, turn on the vibrating screen (for integrated screening crushing stations).
Finally, activate the undersize or return material conveyor belt.
Step 4: Start the main crushing unit
Make sure no materials remain in the crushing chamber.
Press the crusher start button and monitor the starting current, which should quickly drop to the no-load current.
Listen carefully for abnormal noise or vibration during operation.
Step 5: Activate the feeding system
Start the vibrating feeder or belt feeder lastly.
Adjust the feeding speed to the lowest gear to prepare for material feeding.
Step 6: Put into formal production
After all equipment runs under no-load for 1-2 minutes with normal operating parameters.
Use an excavator or loader to feed materials into the hopper with small and uniform feeding at the initial stage.
Gradually increase the feeding volume to 60%-80% of the designed capacity, and monitor crusher load and discharge conditions.
Raise to full load until the entire system runs stably.
III. Key Precautions During Startup
No-load Startup Principle: All crushers, vibrating screens and conveyor belts must be started under no-load conditions. On-load startup will cause motor overload or mechanical damage.
Metal Detection and Iron Removal: If the equipment is equipped with a metal detector or iron remover at the front end, ensure it is started synchronously and operates normally to prevent iron parts from entering the crushing chamber.
Starting Current Monitoring: The peak starting current of the main crusher can reach 5-7 times of the rated current. Shut down the equipment immediately for inspection if the current cannot drop in a short time or abnormal noise occurs.
Reverse Operation Prohibition: Confirm the correct rotation direction marked by arrows before startup. Reverse rotation will reduce crushing efficiency and even damage core components.
Local and Remote Switching: Clarify the current operation mode (local control cabinet or wireless remote control) to avoid misoperation.
IV. Common Startup Faults and Troubleshooting
Phenomenon, Possible Causes, Preliminary Solutions
No response after starting: Emergency stop pressed, power failure, fuse blown — Reset emergency stop button, check main breaker and control fuse.
Tripping immediately after startup: Motor or circuit short circuit, material jamming in crushing chamber — Inspect cable insulation and clean the crushing chamber.
Excessive crusher vibration: Loose base bolts, uneven wear of hammers or jaw plates — Stop the machine to fasten bolts and check wear parts.
>Difficult engine startup: Insufficient fuel, low battery power, low temperature environment — Refuel, check battery and use preheating device.
>Malfunction of hydraulic system: Low oil level, hydraulic pump not started, safety valve not reset — Check oil level and confirm hydraulic pump operating status.
V. Safety Operation Reminders
Sound the horn or send sound and light warnings before startup, and confirm no personnel around the equipment before operation.
It is strictly forbidden for personnel to approach dangerous areas such as feed inlets, crushing chambers and conveyor rollers during equipment operation.
For the first startup or commissioning after maintenance, use jog operation to confirm correct rotation direction.
Operators shall not leave the control position without permission during equipment operation.
Press the emergency stop button immediately in case of abnormalities, and no restart is allowed until hidden dangers are eliminated.
VI. Brief Description of Startup Differences for Different Power Types
Pure Electric Mobile Crushing Station: On-site generator with matched capacity or external municipal power supply is required. Pay attention to the voltage drop when multiple motors start simultaneously, and soft start or star-delta starting mode is recommended.
Diesel Engine Driven Type: Focus on fuel level, battery voltage and ambient temperature. Preheating equipment is required in low-temperature areas. Idle warming up is necessary before loading materials after startup.
Diesel-electric Hybrid Driven Type: The engine drives the generator to supply power for each motor. Start the engine first, and start each actuator in order after the voltage stabilizes.
Conclusion
Correct startup of mobile crushers is the first step to ensure efficient and safe operation. Operators must receive systematic pre-job training, be familiar with the equipment operation manual, and strictly follow the standard process of "pre-start inspection — graded startup — no-load test run — loaded production". Differences exist in electrical logic and hydraulic systems of mobile crushers from different brands and models, so please refer to the official equipment manual as the final basis.
